دانلود نرم افزار شبیه سازی Modbus Slave

(دیدگاه کاربر 9)

396,000 تومان

Modbus Slave

is for simulating up to 32 slave devices in 32 windows!. Speed up your PLC programming with this simulating tools. Start programming and test before you receive your slave device from supplier. Data contained with any open document is accessible to the master application. Same user interface as Modbus Poll. Support function 01, 02, 03, 04, 05, 06, 15, 16, 22 and 23.
Monitoring of serial traffic. OLE Automation for interfacing with Visual Basic, Excel etc. To interpret and show the Modbus data according to your specific requirements. E.g. edit edit your slave data in Excel. Try the Excel example.xls included with the program.
Each window opened within

Modbus Slave

may be configured to represent data from the same or different slave node.

OLE Automation for interfacing with Excel. To interpret and show the Modbus data according to your specific requirements. E.g. edit data in Excel and then transmit the data to your slave device! Try the Excel example.xlsm installed with the program.

جهت دانلود و مطالعه توضیحات نرم افزار به سایت اصلی شرکت سازنده که لینک های آن درتوضیحات زیر قرار دارد مراجعه نمایید

لینک دانلود کرک نرم افزار برای هر دونسخه ۳۲ بیتی و ۶۴ بیتی بعد از پرداخت و تایید سفارش باز خواهد شد.



توضیحات

Modbus Slave is for simulating up to 32 slave devices in 32 windows!. Speed up your PLC programming with this simulating tools. Start programming and test before you receive your slave device from supplier. Data contained with any open document is accessible to the master application. Same user interface as Modbus Poll. Support function 01, 02, 03, 04, 05, 06, 15, 16, 22 and 23.
Monitoring of serial traffic. OLE Automation for interfacing with Visual Basic, Excel etc. To interpret and show the Modbus data according to your specific requirements. E.g. edit edit your slave data in Excel. Try the Excel example.xls included with the program.
Each window opened within Modbus Slave may be configured to represent data from the same or different slave node.

OLE Automation for interfacing with Excel. To interpret and show the Modbus data according to your specific requirements. E.g. edit data in Excel and then transmit the data to your slave device! Try the Excel example.xlsm installed with the program.

Supported protocol variants:

  • Modbus RTU
  • Modbus ASCII
  • Modbus TCP/IP
  • Modbus RTU Over TCP/IP
  • Modbus UDP/IP
  • Modbus RTU Over UDP/IP

MODBUS Slave Technical Facts and Features:

  • OLE Automation for easy interface to Excel using Macro language VBA
  • Print and print preview
  • Monitoring of serial data traffic
  • Context sensitive help
  • ۱۲ Display formats such as float, double etc.
  • Adjustable Address Base (0 or 1)
  • Font and color selection
  • Broadcast (slave ID 0)
  • Easy control of RS-485 converters with RTS toggle

Supported Modbus Functions:

  • ۰۱: Read coil status
  • ۰۲: Read input status
  • ۰۳: Read holding registers
  • ۰۴: Read input registers
  • ۰۵: Force single coil
  • ۰۶: Preset single register
  • ۱۵: Force multiple coils
  • ۱۶: Preset multiple registers
  • ۲۲: Mask write register
  • ۲۳: Read/Write registers

Protocol Description

MODBUS© Protocol is a messaging structure, widely used to establish master-slave communication between intelligent devices. A MODBUS message sent from a master to a slave contains the address of the slave, the ‘command’ (e.g. ‘read register’ or ‘write register’), the data, and a check sum (LRC or CRC).
Since Modbus protocol is just a messaging structure, it is independent of the underlying physical layer. It is traditionally implemented using RS232, RS422, or RS485

The Request

The function code in the request tells the addressed slave device what kind of action to perform. The data bytes contains any additional information that the slave will need to perform the function. For example, function code 03 will request the slave to read holding registers and respond with their contents. The data field must contain the information telling the slave which register to start at and how many registers to read. The error check field provides a method for the slave to validate the integrity of the message contents.

The Response

If the slave makes a normal response, the function code in the response is an echo of the function code in the request. The data bytes contain the data collected by the slave, such as register values or status. If an error occurs, the function code is modified to indicate that the response is an error response, and the data bytes contain a code that describes the error. The error check field allows the master to confirm that the message contents are valid.

Controllers can be setup to communicate on standard Modbus networks using either of two transmission modes: ASCII or RTU.

ASCII Mode

When controllers are setup to communicate on a Modbus network using ASCII (American Standard Code for Information Interchange) mode, each eight-bit byte in a message is sent as two ASCII characters. The main advantage of this mode is that it allows time intervals of up to one second to occur between characters without causing an error.

Coding System
Hexadecimal ASCII printable characters 0 … 9, A … F
Bits per Byte
۱ start bit
۷ data bits, least significant bit sent first
۱ bit for even / odd parity-no bit for no parity
۱ stop bit if parity is used-2 bits if no parity
Error Checking
Longitudinal Redundancy Check (LRC)

RTU Mode
When controllers are setup to communicate on a Modbus network using RTU (Remote Terminal Unit) mode, each eight-bit byte in a message contains two four-bit hexadecimal characters. The main advantage of this mode is that its greater character density allows better data throughput than ASCII for the same baud rate. Each message must be transmitted in a continuous stream.

Coding System
Eight-bit binary, hexadecimal 0 … 9, A … F
Two hexadecimal characters contained in each eight-bit field of the message
Bits per Byte
۱ start bit
۸ data bits, least significant bit sent first
۱ bit for even / odd parity-no bit for no parity
۱ stop bit if parity is used-2 bits if no parity
Error Check Field
Cyclical Redundancy Check (CRC)

In ASCII mode, messages start with a colon ( : ) character (ASCII 3A hex), and end with a carriage return-line feed (CRLF) pair (ASCII 0D and 0A hex).
The allowable characters transmitted for all other fields are hexadecimal 0 … 9, A … F. Networked devices monitor the network bus continuously for the colon character. When one is received, each device decodes the next field (the address field) to find out if it is the addressed device. more…



Modbus Slave

Download Link:

http://www.modbustools.com/download.html

Modbus Slave Simulator

Modbus tools for test, simulation and programming

More Info Link….

http://www.modbustools.com/modbus_slave.html
