برگشتن به نرم افزار

مدیریت و کنترل ماتریسی پاناسونیک

(دیدگاه کاربر 11)

4,640,815 تومان

نرم افزار مدیریت و کنترل ماتریسی آنالوگ/دیجیتال پاناسونیک

سرور WV-ASC970

  • سیستم منعطف هیبریدی با اتصال دوربین های IP و آنالوگ
  • قابلیت ثبت تا حداکثر ۶۴ ریکوردر، ۶۴ انکودر، و ۲۰۴۸ دوربین
  • نمایش تصویر زنده با انتخاب دوربین
  • اتصال همزمان حداکثر ۶۴ کاربر
  • قرارگیری ۶۴ دوربین روی نقشه
  • امکان نمایش ۳۰ دوربین روی صفحه ۱۶ قسمتی

کلاینت مدیریتی WV-ASM970

  • سیستم منعطف هیبریدی با اتصال دوربین های IP و آنالوگ
  • قابلیت ثبت تا حداکثر ۶۴ ریکوردر، ۶۴ انکودر، و ۲۰۴۸ دوربین
  • نمایش تصویر زنده با انتخاب دوربین
  • اتصال همزمان حداکثر ۶۴ کاربر
  • قرارگیری ۶۴ دوربین روی نقشه
  • امکان نمایش ۳۰ دوربین روی صفحه ۱۶ قسمتی

توضیحات

مدل

قیمت (تومان)

موضوع

توضیح

 WV-ASC970

۸,۲۰۰,۰۰۰

IP-Analog Hybrid Matrix server Software

  • Single WV-ASC970 server allows up to 1023 i-Pro devices, 512 monitor screens and 64 recorders in IP only or hybrid system and Up to 1536 analog cameras, 320 analog monitors and 64 recorders in analog only system.
  • H.264, MPEG-4 and JPEG images from i-Pro series are supported. Each camera displayed in a multiscreen can be displayed at up to 30 ips.
  • Camera/Group/Sequence selection, Camera control and Recorder control can be made with the WV-ASM970 or optional system controller WV-CU950.

 WV-ASM970

۷,۰۰۰,۰۰۰

IP-Analog Hybrid Matrix Client Software

 WV-ASE901

۱,۳۰۰,۰۰۰

License for Fire Alarm integration

  • Monitor the status of Fire Alarm System.
  • Manually reset or acknowledge fire alarms and faults of Fire Alarm System.
  • Search history of fire alarm, faults and interlocking of Fire Alarm System.

WV-ASC970

WV-ASC970 provides a true virtual matrix allowing the user to create a Hybrid solution and full control of both IP and analogue systems. The virtual matrix allows the registration of up to 64 recorders, 64 encoders and 2048 cameras. Live images can be selected, as well as full control of presets and group sequences. ASC970 allows registration of up to 512 users and 64 can be logged on simultaneously. WV-ASM970 gives full control of both IP and Analogue systems. Up to 30ips can be displayed in 16 split screen in either MPEG-4 or H.264. Multi monitor option enables use of operation and monitor screen simultaneously. Upon alarm notification, monitor changes into map mode where up to 64 cameras can be freely positioned on a map.

WV-ASE902 Extension Unit

With the new WV-ASE902 extension software, the System970 increases efficiency of video surveillance operation by displaying up to 64 video sources on the monitor screens. The WV-ASM970 client of System970 with theWV-ASE902 supports up to four monitor displays with 16-screen split and one operation display, resulting in 64 monitor windows per client system. The WV-ASE902 extension software is available with the version 10 or later of theWV-ASC970 and WV-ASM970 IPMatrix Server/Client Software of System970.

WV-ASM970

WV-ASC970 provides a true virtual matrix allowing the user to create a Hybrid solution and full control of both IP and analogue systems. The virtual matrix allows the registration of up to 64 recorders, 64 encoders and 2048 cameras. Live images can be selected, as well as full control of presets and group sequences. ASC970 allows registration of up to 512 users and 64 can be logged on simultaneously. WV-ASM970 gives full control of both IP and Analogue systems. Up to 30ips can be displayed in 16 split screen in either MPEG-4 or H.264. Multi monitor option enables use of operation and monitor screen simultaneously. Upon alarm notification, monitor changes into map mode where up to 64 cameras can be freely positioned on a map
